Stylish design with adjustable steering wheel for comfort, high-top air intake for engine protection, wide-view door frame, LCD instrument panel, and optional low-maintenance cast axle.
2.5 TON DIESEL FORKLIFT
Rated load：2500kg
Wheelbase：1600mm
Operating weight：3680kg
The backbone of the Lugong ER4T design: The legendary articulated oscillating floating joint. All four wheels remain in constant contact with the ground and the machine moves with maximum traction, In addition, the machine has unrivalled manceuyrability
| Main Technical Parameters | ||
| Rated load | KG | 2500 |
| Load center | mm | 500 |
| Overall length | mm | 3646 |
| Width | mm | 1170 |
| Overhead guard height | mm | 2070 |
| Wheelbase | mm | 1600 |
| Ground clearance | mm | 110 |
| Turning radius | mm | 2240 |
| Front tire | 7 00×12-12PR | |
| Rear tire | 6.00×9-10PR | |
| Fork size | mm | 1070*100*45 |
| Operating weight | KG | 3680 |
| Engine model | Quancha14C2-50V32 | |
